# 💥PoW! Bot Deterrent
A proof-of-work based bot deterrent. Lightweight, self-hosted and copyleft licensed.
Compared to mainstream captchas like recaptcha, hcaptcha, friendlycaptcha, this one is better for a few reasons:
- Free as in Freedom, and Free as in Free Beer
- It is lightweight & all dependencies are included; total file size is about 68KB unminified / uncompressed, and 23kb gzipped.
- It is self-hosted. It does not spy on you or your users; you can tell because you run it on your own server, you wholly own and control it.
- If you wish to use the one that I host instead of running it yourself, just let me know. Maybe we can work something out.
Compared to other proof of work bot deterrents like mCaptcha, I believe that this one is better because:
- It uses a multi-threaded [WASM (Web Assembly)](https://webassembly.org/) [WebWorker](https://developer.mozilla.org/en-US/docs/Web/API/Web_Workers_API/Using_web_workers) running the [Scrypt hash function](https://en.wikipedia.org/wiki/Scrypt) instead of [SHA256](https://en.wikipedia.org/wiki/SHA-2). Because of this, it's:
- 1. Fundamentally harder to accelerate.
- 1. More likely to stop bots; a basic headless browser with JS execution might not be enough.
- It is optimized for production use; its API minimizes the number of requests and amount of latency that you have to add to your system.
### Table of Contents
1. [How it works](#how-it-works)
1. [What is Proof of Work?](#what-is-proof-of-work)
1. [Overview sequence diagram](#overview-sequence-diagram)
1. [Configuring](#configuring)
1. [HTTP Challenge API](#http-challenge-api)
1. [HTTP Admin API](#http-admin-api)
1. [HTML DOM API](#html-dom-api)
1. [Running the example app](#running-the-example-app)
1. [Implementation walkthrough via example app](#implementation-walkthrough-via-example-app)
1. [Implementation Details for Developers](#implementation-details-for-developers)
1. [What is Proof of Work? Extended Concrete Example](#what-is-proof-of-work-extended-concrete-example)
# How it works
This application was designed to be a drop-in replacement for ReCaptcha by Google. It works pretty much the same way;
1. Your web application requests a challenge (in this case, a batch of challenges) from the challenge HTTP API
2. Your web application displays an HTML page which includes a form, and passes the challenge data to the form
3. The HTML page includes the JavaScript part of the Bot Deterrent app, this JavaScript draws a progress bar on the page
4. When the Proof of Work is complete, its JavaScript will fire off a callback to your JavaScript
5. When the form is submitted, your web application submits the nonce (solution) to the challenge HTTP API for validation
# What is Proof of Work?
Proof of Work (PoW) is a scheme by which one computer can prove to another that it expended a certain amount of computational effort.
PoW does not require any 3rd party or authority to enforce rules, it is based on mathematics and the nature of the universe.
PoW works fairly well as a deterrent against spam, a PoW requirement makes sending high-volume spam computationally expensive.
It is impossible to predict how long a given Proof of Work will take to calculate. It could take no time at all (got it on the first try 😎 ), or it could take an abnormally long time (got unlucky and took forever to find the right hash 😟 ). You can think of it like flipping coins until you get a certain # of heads in a row. This **DOES** matter in terms of user interface and usability, so you will want to make sure that the difficulty is low enough that users are extremely unlikely to be turned away by an unlucky "takes forever" challenge.
The word ["Nonce"](https://en.wikipedia.org/wiki/Cryptographic_nonce#Hashing) in this document refers to "Number Used Once", in the context of hashing and proof of work.
If you want to read more or see a concrete example, see [What is Proof of Work? Extended Concrete Example](#what-is-proof-of-work-extended-concrete-example) at the bottom of this file.
# Overview sequence diagram
This diagram was created with https://app.diagrams.net/.
To edit it, download the diagram file and edit it with the https://app.diagrams.net/ web application, or you may run the application from [source](https://github.com/jgraph/drawio) if you wish.
# Configuring
💥PoW! Bot Deterrent gets all of its configuration from environment variables.
#### `POW_BOT_DETERRENT_ADMIN_API_TOKEN`
⚠️ **REQUIRED**
This token allows control of the Admin API & allows the bearer to create, list, and revoke application tokens.
----
#### `POW_BOT_DETERRENT_BATCH_SIZE`
💬 *OPTIONAL* default value is 1000
How many challenges to return at once.
----
#### `POW_BOT_DETERRENT_DEPRECATE_AFTER_BATCHES`
💬 *OPTIONAL* default value is 10
How many "batches-old" challenges can be before being dropped from memory.
----
#### `POW_BOT_DETERRENT_LISTEN_PORT`
💬 *OPTIONAL* default value is 2730
Which TCP port should the server listen on.
----
#### `POW_BOT_DETERRENT_SCRYPT_CPU_AND_MEMORY_COST`
💬 *OPTIONAL* default value is 4096
Allows you to tweak how difficult each individual hash in the proof of work will be.
----
# HTTP Challenge API
#### `POST /GetChallenges?difficultyLevel=`
Required Header: `Authorization: Bearer `
Return type: `application/json`
`GetChallenges` returns a JSON array of 1000 strings. The Bot Deterrent server will remember each one of these challeges until it is
restarted, or until GetChallenges has been called 10 more times. Each challenge can only be used once.
The difficultyLevel parameter specifies how many bits of difficulty the challenges should have.
Each time you increase the difficultyLevel by 1, it doubles the amount of time the Proof of Work will take on average.
The recommended value is 5. A difficulty of 5 will be solved quickly by a laptop or desktop computer, and solved within 60 seconds or so by a cell phone.
#### `POST /Verify?challenge=&nonce=`
Required Header: `Authorization: Bearer `
Return type: `text/plain` (error/status messages only)
`Verify` returns HTTP 200 OK only if all of the following are true:
- This challenge was returned by `GetChallenges`.
- `GetChallenges` hasn't been called 10 or more times since this challenge was originally returned.
- `Verify` has not been called on this challenge before.
- The provided hexadecimal nonce solves the challenge.
- (The winning nonce string will be passed to the function you specify in [data-pow-bot-deterrent-callback](#data-pow-bot-deterrent-callback). You just have to make sure to post it to your server so your server can include it when it calls `/Verify`)
Otherwise it returns 404, 400, or 500.
#### `GET /static/`
Return type: depends on file
Files:
- pow-bot-deterrent.js
- pow-bot-deterrent.css
- proofOfWorker.js
You only need to include `pow-bot-deterrent.js` in your page, it will pull in the other files automatically if they are not already present in the page.
See below for a more detailed implementation walkthrough.
# HTTP Admin API
#### `GET /Tokens`
Required Header: `Authorization: Bearer `
Return type: `text/plain`
Lists all existing api tokens in CSV format, including the token itself, the name, and when it was created.
#### `POST /Tokens/Create?name=`
Required Header: `Authorization: Bearer `
Return type: `text/plain`
Creates a new given API token with the given name and returns the token as a plain text hexadecimal string.
#### `POST /Tokens/Revoke?token=`
Required Header: `Authorization: Bearer `
Return type: `text/plain` (error/status messages only)
Revokes an existing API token.
# HTML DOM API
In order to set up 💥PoW! Bot Deterrent on your page, you just need to load/include `pow-bot-deterrent.js` and one or more html elements
with all 3 of the following properties:
#### `data-pow-bot-deterrent-url`
This is the base url from which `pow-bot-deterrent.js` will attempt to load additional resources `pow-bot-deterrent.css` and `proofOfWorker.js`.
> 💬 *INFO* In our examples, we passed the Bot Deterrent server URL down to the HTML page and used it as the value for this property.
However, that's not required. The HTML page doesn't need to talk to the Bot Deterrent server at all, it just needs to know where it can
download the `pow-bot-deterrent.css` and `proofOfWorker.js` files. There is nothing stopping you from simply hosting those files on your own server or CDN and placing the corresponding URL into the `data-pow-bot-deterrent-url` property.
#### `data-pow-bot-deterrent-challenge`
Set this property to one of the challenge strings returned by `GetChallenges`. It must be unique, each challenge can only be used once.
⚠️ **NOTE** that the element with the 3 `pow-bot-deterrent-xyz` data properties **MUST** be placed **inside a form element**. This is required, to allow the bot deterrent to know which input elements it needs to trigger on. We only want it to trigger when the user actually intends to submit the form; otherwise we are wasting a lot of their CPU cycles for no reason!
#### `data-pow-bot-deterrent-callback`
This is the name of a function in the global namespace which will be called & passed the winning nonce once the Proof of Work
is completed. So, for example, if you had:
``
Then you would provide your callback like so:
```
```
> 💬 *INFO* You may also nest the callback inside object(s) if you wish:
``
```
```
When `pow-bot-deterrent.js` runs, if it finds an element with `data-pow-bot-deterrent-challenge` & `data-pow-bot-deterrent-callback`, but the callback function is not defined yet, it will print a warning message. If the callback is still not defined when the Proof of Work is completed, it will throw an error.
> 💬 *INFO* the element with the `pow-bot-deterrent` data properties should probably be styled to have a very small font size. When I was designing the css for the bot deterrent element, I made everything scale based on the font size (by using `em`). But because the page I was testing it on had a small font by default, I accidentally made it huge when it is rendered on a default HTML page. So for now you will want to make the font size of the element which contains it fairly small, like `10px` or `11px`.
#### `window.botBotDeterrentInit`
The bot deterrent event listeners, elements, css, & webworkers **won't be loaded until this function is called**.
**`pow-bot-deterrent.js` will call this function automatically** if there's at least one DOM element with `data-pow-bot-deterrent-challenge` already when `pow-bot-deterrent.js` loads. Otherwise, it is up to you to call this function after you render the DOM elements & add the `data-pow-bot-deterrent-challenge` property to them.
This function will throw an error if it is called more than once without calling `window.powBotDeterrentReset()` in between.
For example:
```
```
#### `window.powBotDeterrentReset`
Resets the bot deterrent(s), stops the webworkers, etc. Use this if you have updated the page and you need to call `window.botBotDeterrentInit` again.
#### `window.botBotDeterrentInitDone`
A boolean variable that `pow-bot-deterrent.js` uses internally, so it can know if it has already been initialized or not.
----
If you wanted to integrate 💥PoW! Bot Deterrent with a JavaScript driven front-end app, like a React-based app for example, you can install it via npm:
`npm install git+https://git.sequentialread.com/forest/pow-bot-deterrent.git`
and use it like this:
```
import {React, useEffect, useState} from 'react';
...
import '../node_modules/pow-bot-deterrent/static/pow-bot-deterrent.css'
import '../node_modules/pow-bot-deterrent/static/pow-bot-deterrent.js'
// assumes that this component gets passed the botDeterrentURL and challenge as props
// these would be loaded/passed from the server somehow. Especially the challenge, it has to be unique each time.
function MyComponent({botDeterrentURL, challenge}) {
// When the component is created, set a unique string to be used as the callback in the global namespace (window)
const [uniqueCallback] = useState(`pow-bot-deterrent-callback-${String(Math.random()).substring(6)}`);
// when the nonce is calculated, we will call setNonce
const [nonce, setNonce] = useState("");
// because this useEffect will cause the WebWorkers to be re-created each time, which could get expensive,
// you will want to ensure that this component does not somehow flicker in and out of existence
useEffect(() => {
window[uniqueCallback] = (winningNonce) => {
setNonce(winningNonce);
}
// Maybe less clear than the above, but JavaScript heads might enjoy this more:
// window[uniqueCallback] = setNonce;
if(window.botBotDeterrentInitDone) {
window.powBotDeterrentReset();
}
window.botBotDeterrentInit();
}, [uniqueCallback]);
return (
);
}
```
# Running the example app
The `example` folder in this repository contains an example app that demonstrates how to implement the 💥PoW! Bot Deterrent
in as simple of a fashion as possible.
If you wish to run the example app, you will have to run both the 💥PoW! Bot Deterrent server and the example app server.
The easiest way to do this would probably be to open two separate terminal windows or tabs and run each app in its own terminal.
#### `terminal 1`
```
forest@thingpad:~/Desktop/git/pow-bot-deterrent$ go run main.go
panic: can't start the app, the POW_BOT_DETERRENT_ADMIN_API_TOKEN environment variable is required
goroutine 1 [running]:
main.main()
/home/forest/Desktop/git/pow-bot-deterrent/main.go:84 +0xf45
exit status 2
```
As you can see, the server requires an admin API token to be set. This is the token we will use authenticate and create
individual tokens for different apps or different people who all might want to use the bot deterrent server.
Once we provide this admin API token environment variable, it will run just fine:
```
forest@thingpad:~/Desktop/git/pow-bot-deterrent$ POW_BOT_DETERRENT_ADMIN_API_TOKEN="example_admin" go run main.go
2021/02/25 16:24:00 💥 PoW! Bot Deterrent server listening on port 2370
```
Now let's try to launch the example Todo List application:
#### `terminal 2`
```
forest@thingpad:~/Desktop/git/pow-bot-deterrent$ cd example/
forest@thingpad:~/Desktop/git/pow-bot-deterrent/example$ go run main.go
panic: can't start the app, the BOT_DETERRENT_API_TOKEN environment variable is required
goroutine 1 [running]:
main.main()
/home/forest/Desktop/git/pow-bot-deterrent/example/main.go:40 +0x488
exit status 2
```
It's a similar story for the example app, except this time we can't just make up any old token, we have to ask the Bot Deterrent server to generate a new API token for the example app. I will do this by manually sending it an http request with `curl`:
```
$ curl -X POST -H "Authorization: Bearer example_admin" http://localhost:2370/Tokens/Create
400 Bad Request: url param ?name= is required
$ curl -X POST -H "Authorization: Bearer example_admin" http://localhost:2370/Tokens/Create?name=todo-list
b804f221e8a9053b2e6e89de83c5d7a4
```
Now we can use this token to start the example Todo List app:
```
$ BOT_DETERRENT_API_TOKEN="b804f221e8a9053b2e6e89de83c5d7a4" go run main.go
2021/02/25 16:38:32 📋 Todo List example application listening on port 8080
```
Then, you should be able to visit the example Todo List application in the browser at http://localhost:8080.
# Implementation walkthrough via example app
Lets walk through how example app works and how it integrates the 💥PoW! Bot Deterrent.
The Todo List app has three pieces of configuration related to the bot deterrent: the API token, the url, and the difficulty.
Currently the url and difficulty are hardcoded into the Todo List app's code, while the API token is provideded via an environment variable.
```
// 5 bits of difficulty, 1 in 2^5 (1 in 32) tries will succeed on average.
//
// 7 bits of difficulty would be fine for apps that are never used on mobile phones, 5 is better suited for mobile apps
//
const difficultyLevel = 5
...
apiToken := os.ExpandEnv("$BOT_DETERRENT_API_TOKEN")
if apiToken == "" {
panic(errors.New("can't start the app, the BOT_DETERRENT_API_TOKEN environment variable is required"))
}
powAPIURL, err = url.Parse("http://localhost:2370")
```
When the Todo List app starts, it has a few procedures it runs through to ensure it's ready to run, including
retrieving a batch of challenges from the bot deterrent API:
```
func main() {
...
err = loadChallenges()
if err != nil {
panic(errors.Wrap(err, "can't start the app because could not loadChallenges():"))
}
```
`loadChallenges()` calls the `GetChallenges` API & sets the global variable `powChallenges`.
It's a good idea to do this when your app starts, to ensure that it can talk to the Bot Deterrent server before it starts serving content to users.
The Todo List app only has one route: `/`.
This route displays a basic HTML page with a form, based on the template `index.html`.
```
http.HandleFunc("/", func(responseWriter http.ResponseWriter, request *http.Request) {
...
})
```
This route does 4 things:
1. If it was a `POST` request, call the `Verify` endpoint to ensure that a valid challenge and nonce were posted.
- see `validatePow` on line 202.
2. If it was a *valid* `POST` request, add the posted `item` string to the global list variable `items`.
3. Check if the global `powChallenges` list is running out, if it is, kick off a background process to grab more from the `GetChallenges` API.
- see `loadChallenges` on line 155.
4. Consume one challenge string from the global `powChallenges` list variable and output an HTML page containing that challenge.
The challenge API (`GetChallenges` and `Verify`) was designed this way to optimize the performance of your application; instead of calling something like *GetChallenge* for every single request, your application can load batches of challenges asychronously in the background, and always have a challenge loaded into local memory & ready to go.
However, you have to make sure that you are using it right:
- You must ensure that you only serve each challenge once, and
- You must only call `GetChallenges` when necessary (when you are running out of challenges). If you call it too often you may accidentally expire otherwise-valid challenges before they can be verified.
- Note that for high-traffic web sites where multiple requests can hit the server at once, you should probably use a [lock, mutex](https://git.sequentialread.com/forest/sequentialread-comments/src/af2f999134214412c1c6cf32c458e9b8a8c88289/main.go#L278), partitioning scheme, or other thread safe data structure to ensure that two concurrent requests don't end up trying to grab the same challenge from the list ([Software Race Condition](https://en.wikipedia.org/wiki/Race_condition#Software)).
---
Anyways, lets get on with things & look at how the Todo List app renders its HTML page.
There are two main important parts, the form and the javascript at the bottom:
```
...
```
⚠️ **NOTE** that the element with the `pow-bot-deterrent` data properties is placed **inside a form element**. This is required because the bot deterrent needs to know which input elements it should trigger on. We only want it to trigger when the user actually intends to submit the form; otherwise we are wasting a lot of their CPU cycles for no reason!
> 💬 *INFO* The double curly brace elements like `{{ .Challenge }}` are Golang string template interpolations. They are specific to the example app & how it renders the page.
When the page loads, the `pow-bot-deterrent.js` script will execute, querying the page for all elements with the `data-pow-bot-deterrent-challenge`
property. It will then validate each element to make sure it also has the `data-pow-bot-deterrent-url` and `data-pow-bot-deterrent-callback` properties. For each element it found, it will locate the `
